M12 A-code 8Pin Male Shielded Connector
Item No: N-25174-1
An M12 A-coded 8-pin male connector is widely used in industrial automation for simultaneous sensor, actuator, and network data or power transmission. It features protruding contact pins, an external thread, and a single keyway A-coding design to prevent mismatched connections. [1, 2]
Common Applications
- Sensor and Actuator Networks: Connecting multi-channel sensor blocks and control units.
- IO-Link and DeviceNet: Linking smart field devices and modular networks.
- Fieldbus and Signal Wiring: Handling up to 8 conductor straight-wire low-voltage analog or digital signals.
- Factory Automation: Used across material handling, assembly lines, and harsh environment machinery requiring IP67 protection.
Description
An M12 A-coded 8-pin male connector is widely used in industrial automation for simultaneous sensor, actuator, and network data or power transmission. It features protruding contact pins, an external thread, and a single keyway A-coding design to prevent mismatched connections.
Common Applications:
- Sensor and Actuator Networks: Connecting multi-channel sensor blocks and control units.
- IO-Link and DeviceNet: Linking smart field devices and modular networks.
- Fieldbus and Signal Wiring: Handling up to 8 conductor straight-wire low-voltage analog or digital signals.
- Factory Automation: Used across material handling, assembly lines, and harsh environment machinery requiring IP67 protection.
| No. of Contacts | 8 Pins |
| Coding | A Code |
| Connector Gender | Male Connector |
| Orientation | Straight |
| Housing Material | PBT UL94V-0, Black |
| Contact Material | Brass with Gold Flash |
| Nut Material | Brass with Nickel-plated |
| Shell Material | Brass with Bright Tin-plated |
| O-Ring Material | EPDM |
| Rated Current | 2A |
| Rated Voltage | 30V |
| Waterproof | IP67 |
| Operation Temperature | -40℃ ~ 105℃ |
